Tessellate surfaces via polylines and meshes (2 hrs)
The goal of this tutorial is to develop gridshell and tessellation strategies using parametric surface control. Students will learn to construct gridshells from uniform and non-uniform surface parametrisations, generate mesh topologies and polyline cells, create diagrid structures, and explore topological variations. The tutorial focuses on translating continuous surfaces into discrete structural frameworks.
Tutorial Overview
Duration approx. 2 hrs.
The tutorial progressively covers:
- 01 | Construct a Gridshell from a Uniform Surface Parametrisation
- 02 | Construct a Gridshell from a Non-Uniform Surface Parametrisation (math function control)
- 03 | Construct Mesh Topology from a point grid
- 04 | Construct Polyline Cells from a point grid
- 05 | Generate a Diagrid through Polyline cells
- 06 | Generate a Diagrid through Mesh faces
- 07 | Generate topological variations of a Diagrid Mesh
- 08 | Integrate Surface Parameterisation and Tessellation Scripts
